Cutting edge technology brings simple, accurate utility location
The new Leica DD130 simplifies and streamlines the utility location and tracing process. For all professionals who need to accurately locate and trace buried utilities, the DD130 cable locator features additional tracing capabilities and increased depth detection in an easy, intuitive product. The DD130 delivers consistent and precise location capabilities for increased user confidence.
- Automatic pinpointing
- Power, Radio, Auto modes
- Transmitter, 33kHz, 8kHz
- Depth detection up to 3 meters (10 feet)
- Good-to-Go™ Health Check and Start up test
- Extended trace range with additional 512Hz, 640Hz frequencies
- Signal current measurement
- Increased depth detection up to 10 metres (33 feet)
- IP54 rating - protection from dust and water
- 1 year Warranty
Handheld multi-frequency underground service locator
The Leica DD100 Series cable locators feature advanced automatic controls making the DD100 Series easy-to-use, requiring minimal user experience. Avoiding underground cables and pipes is a major concern on construction sites. Therefore, detecting the position of buried cables and pipes before excavation work can help prevent operator injury, asset damage and any subsequent costs. Use the DD120 or DD130 cable locators in conjunction with a DA220 or DA230 signal transmitter or range of accessories to achieve improved accuracy and application scope.
Unmatched ease of use
With Automatic Pinpointing there is no need for you to manually adjust the sensitivity of your Digicat cable locator ensuring you’re using the optimum sensitivity for the environment you are detecting the underground utilities in. Reducing the likelihood of human error and enabling easier and more efficient cable and pipe locating. Ultimately saving you time and money.
DD100 Series Technical Specifications
| MODE | DD120 | DD130 |
| Power | 50Hz model or 60Hz model | 50Hz model or 60Hz model |
| Radio | 15kHz to 60kHz | 15kHz to 60kHz |
| Auto | Power, Radio, 33kHz | Power, Radio, 33kHz |
| Transmitter Modes | 32.768 (33) kHz 8.192 (8) kHz |
32.768 (33) kHz 8.192 (8) kHz 512 Hz 640 Hz |
| Depth Range | Line 0.3m to 3m / 1ft to 10 ft Sonde 0.3m to 3m / 1ft to 10 ft |
Line 0.3m to 3m / 1ft to 10ft Sonde 0.3m to 9.99m / 1 ft to 32.77 ft |
| Depth Accuracy* | 10% | 10% |
| Environmental Standard | IP54 | IP54 |
| Operating Temperature | -20° C to +50° C -4° F to +122° F |
-20° C to +50° C -4° F to +122° F |
| Battery | 6 x LR6 (AA) Alkaline | 6 x LR6 (AA) Alkaline |
| Battery operating time** | 15 h | 15 h |
| Dimensions (HxWxD) | 760 x 250 y 85mm (30 x 10 x 3.4 inches) |
760 x 250 y 85mm (30 x 10 x 3.4 inches) |
| Weight with batteries | 2.7Kg 5.95 lbs |
2.7Kg 5.95 lbs |
| * Depth to an undistorted signal ** Constant use at 20°C/68°F |
||
| SKU | 872940 |
|---|---|
| MPN | 872940 |
| Brand | Leica Geosystems |
| Package Includes | N/A |
